This product is suitable for conveying slurry containing abrasive particles such as sand, coal cinder and tailings. It is suitable for mines, coal mines, metallurgy, electric power, environmental protection, river dredging, sand pumping, municipal engineering, etc. This product is easy to install and move, has high slag pumping efficiency, and can operate safely for a long time under harsh working conditions. It is an ideal product to replace traditional vertical underarm pumps and submersible sewage pumps.
Main Parts:
Impeller, Casing，Bearing assembly，Shaft Sleeve (Long)，Strainer，Discharge Bend，Frame Plate Liner Insert，etc
Main material:
Cr27,Cr28,CD4Mcu, Rubber, etc.
Advantage:
1. More advanced hydraulic model, sealing technology, protection control;
2. Simple structure, easy installation, safe and reliable use, long life;
3. There is no need to build complex ground pump rooms and fixtures, no noise and vibration, and the work site is cleaner.
Specifications and Performance：
|
Type |
Caliber |
Capacity Q |
Head |
Power |
Speed |
|
50ZJQ25-9-4/4 |
50 |
25 |
9 |
4 |
1450 |
|
65ZJQ20-20-4/4 |
65 |
20 |
20 |
4 |
1450 |
|
80ZJQ35-10-4/4 |
80 |
35 |
10 |
4 |
1450 |
|
80ZJQ30- 25-5.5/4 |
80 |
30 |
25 |
5.5 |
1450 |
|
100Z JQ40-15-5.5/4 |
100 |
40 |
15 |
5.5 |
1450 |
|
80ZJQ30 -30 -7.5/4 |
80 |
30 |
30 |
7.5 |
1450 |
|
100ZJQ50-15-7.5/4 |
100 |
50 |
15 |
7.5 |
1450 |
|
65ZJQ20-40-11/2 |
65 |
20 |
40 |
11 |
2900 |
|
80ZJQ70- 20-11/4 |
80 |
70 |
20 |
11 |
1450 |
|
100ZJQ100-10-11/4 |
100 |
100 |
10 |
11 |
1450 |
|
80ZJQ70-25-15/4 |
80 |
70 |
25 |
15 |
1450 |
|
100ZJQ80-20-15/4 |
100 |
80 |
20 |
15 |
1450 |
|
100ZJQ100-15-15/4 |
100 |
100 |
15 |
15 |
1450 |
|
150ZJQ200-10-15/6 |
150 |
200 |
10 |
15 |
980 |
|
65ZJQ30-55-18.5/2 |
65 |
30 |
55 |
18.5 |
2900 |
|
80ZJQ70-30-18.5/4 |
80 |
70 |
30 |
18.5 |
1450 |
|
100ZJQ100-22-18.5/4 |
100 |
100 |
22 |
18.5 |
1450 |
|
100ZJQ100-28-22/4 |
100 |
100 |
28 |
22 |
1450 |
|
150ZJQ200-15-22/4 |
150 |
200 |
15 |
22 |
1450 |
|
80Z JQ30-80-30/2 |
80 |
30 |
80 |
30 |
2900 |
|
100ZJQ100-40-30/4 |
100 |
100 |
40 |
30 |
1450 |
|
150ZJQ150- 30-30/4 |
150 |
150 |
30 |
30 |
1450 |
|
80ZJQ30-90-37/2 |
80 |
30 |
90 |
37 |
2900 |
|
100ZJQ100-45-37/4 |
100 |
100 |
45 |
37 |
1450 |
|
150ZJQ200-25-37/4 |
150 |
200 |
25 |
37 |
1450 |
|
100ZJQ100-50-45/4 |
100 |
100 |
50 |
45 |
1450 |
|
150ZJQ200- 30-45/4 |
150 |
200 |
30 |
45 |
1450 |
|
200ZJQ300-24-45/4 |
200 |
300 |
24 |
45 |
1450 |
|
200ZJQ400- 20-45/4 |
200 |
400 |
20 |
45 |
1450 |
|
200ZJQ300- 30-55/4 |
200 |
300 |
30 |
55 |
1450 |
|
200ZJQ400-20-55/4 |
200 |
400 |
20 |
55 |
1450 |
Note：For detailed selection of flow rate, head, specific gravity, and equipped power, please consult us.
